Product Description
Features/Benefits:
- Independent lab certified air flow rates for increased worker safety, productivity plus, meeting stringent Federal & State OSHA requirements.
- Heavy-duty, rotomolded housing construction takes serious abuse, protects the impeller, keeps air flowing
- Heavy-duty protective screens for safety, keeping large debris, hands & fingers from impeller
- Radial impeller design reduces drag, ensures high efficiency output even at high static pressure levels
- Adjustable, easy access, speed control for matching air flow requirements to jobsite conditions
- Rugged spring mounted frame isolates engine vibration, keeps blower in place
- Honda®3.5 HP gasoline engine for reliable power, performance & low maintenance
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Ventilation Applications | Outdoor use for general air circulation, spot cooling, exhausting fumes, detecting sewer leaks in confined spaces & similar uses in non-confined space areas where other power source options are not available or practical |
| Power Source | |
|---|---|
| Motor | 3.5 HP (2.6 Kw), Honda, GX120, 4-Stroke, gasoline engine |
| Maximum RPM | 3600.0 |
| Speed Control | Manual |
| Blower | |
|---|---|
| Nominal Diameter | 8.0 inches (203.2 mm) |
| Housing Construction | Rotomolded polymer |
| Impeller Construction | Cast aluminum |
| Mounting Type | Spring anti-vibration |
| Ducting | Optional 8.0 inch (203.2 mm) diameter available in one length |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 19.3 x 15.6 x 18.5 inches (490.2 x 396.2 x 470.0 mm) |
| Product Weight | 66.0 lbs (29.9 kg), less ventilation duct |
| Air Flow Rates | |
|---|---|
| Configuration | ACFM 15.0 Ft Duct |
| Free Air (Less Duct/Canister) | 1561.6 CFM (44.2 CMM) |
| One 90° Bend | 1178.1 CFM (33.4 CMM) |
| Two 90° Bend | 1066.2 CFM (30.2 CMM) |
Downloads
| Literature | Description | Version |
|---|---|---|
| GP8H VELOCIMAX™ Series Ventilation Blower | GEF01111003 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| GP8-GP8H VELOCIMAX™ SERIES VENTILATION BLOWER OPERATOR MANUAL (US VERSION) | GOM-1020872 | 1.1 |
| Parts | Description | Version |
|---|---|---|
| GP8-GP8H VELOCIMAX VENTILATION BLOWER PARTS (US VERSION) | PGOM-1020872 | 1.1 |
| Application Information | Description | Version |
|---|---|---|
| Portable Air Ventilation Blower Use During Confined Work Space Entry | GEF10791091 | 1.0 |
| MSDS | Version |
|---|---|
| 300-Series-Transmission-Lubricant | 1.0 |
