Product Description
Features/Benefits:
- CSA certified, multi-point, spark-proof construction to ensure your safety
- Corrosion resistant, aluminum motor housing, housing screens & base plus, blower housing
- Corrosion resistant, aluminum screws & duct attachment knobs
- PVC coated carry handle plus, galvanized coated intake & exhaust screens
- Integral, self-contained ON/OFF switch with no external wiring
- Explosion-proof, totally enclosed, non-vented (TENV) electric motor
- Hard use cable with spark & ignition-proof plug
- Secondary static dispersal system with dual ground path through power cable & duct clamps
- Optional statically conductive ducting and aluminum storage canister
- Independent lab certified air flow rates for increased worker safety, productivity plus, meeting stringent Federal & State OSHA requirements.
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Hazardous/non-hazardous type locations |
| Ventilation Applications | National Electric Code Class I Group D, Class II Group G and Class III hazardous plus, non-hazardous location atmospheres for such things as general fresh air circulation to spot cooling, exhausting fumes & detecting sewer leaks |
| Power Source | |
|---|---|
| Electric Motor | .33 HP (.25 Kw) 115 VAC, 60 HZ, single speed, explosion-proof, totally enclosed, non-vented (TENV) electric motor |
| Blower | |
|---|---|
| Nominal Diameter | 8.0 inches (203.2 mm) |
| Housing Construction | Cast aluminum |
| Impeller Construction | Steel, multi-vane |
| Power Cord | 14-3, SOW x 8.5 ft (2.6 M) L, extra hard use cable |
| Cord Cap | Appleton NCP2023 or equivalent rated for hazardous location use |
| Ducting | Optional statically conductive 8.0 inch (203.2 mm) diameter x 25.0 ft (7.6 M) |
| Agency Certifications | CSA |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 18.9 x 15.4 x 19.9 inches (480.1 x 391.2 x 505.5 mm) |
| Product Weight | 73.0 lbs (33.1 kg), less ventilation duct |
| Air Flow Rates | |
|---|---|
| Configuration | ACFM 15.0 Ft Duct |
| Free Air (Less Duct) | 1277.4 CFM (36.2 CMM) |
| One 90° Bend | 738.0 CFM (20.9 CMM) |
| Two 90° Bend | 578.8 CFM (16.4 CMM) |
Downloads
| Literature | Description | Version |
|---|---|---|
| EP8HL VELOCIMAX™ Series Ventilation Blower | GEF27101001 | 0.0 |
| Manuals | Description | Version |
|---|---|---|
| EP8HL Hazardous Location Blower Operator Manual | GOM7069501 | 1.3 |
| Parts | Description | Version |
|---|---|---|
| EP8HL Hazardous Location Ventilation Blower Parts | PGOM7069501 | 1.3 |
| Application Information | Description | Version |
|---|---|---|
| Portable Air Ventilation Blower Use During Confined Work Space Entry | GEF10791091 | 1.0 |
