Product Description
Features/Benefits:
- Honda® GXV390 gasoline engine for reliable power & performance
- Balanced weight design for ease of handling and maneuverability reducing stress & strain increasing productivity
- Gimbaled grinding heads follow surface contours for optimal surface finishing results
- 2-position operator handle improves worker ergonomics plus, folds for reduced transportation & storage footprint
- Low RPM operation minimizes bouncing & shimmies for safe control, helps prevent surface damage
- Central bearing lubrication system & integral v-belt tensioning for quick maintenance & reduced downtime
- Height adjustable rear wheels to match grinding attachments for even wear & grinding performance
- Height adjustable dust shield matches grinding attachments, keeps dust contained & workers safe
- Accepts interchangeable industry wedge-type retained attachments for max optimization & multi-job flexibility
- Meets OSHA silica dust requirements keeping workers safe
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Surface Preparation Applications | Grinding, scraping, coatings removal, scarifying & polishing of concrete plus grinding & scarifying of asphalt |
| Power Source | |
|---|---|
| Power Source | 13.0 HP (9.7 Kw) Honda, GXV390, 4 Stroke, gas engine |
| Starter | Hand rewind |
| Fuel | Gasoline, unleaded, automotive grade |
| Frame | |
|---|---|
| Frame | Unitized, welded steel plate |
| Drive System | V-belt/spur gear-type reduction |
| Multi-Accessory Disc Configuration | Two each, aluminum, 12.0 inch (304.8 mm) diameter, elastomeric mounted attachment discs for use with plastic wedges |
| Nominal Disc Rotation Speed | 250.0 RPM |
| Dust Port Connection | 3.0 inch (76.2 mm) diameter |
| General | |
|---|---|
| Product Dimensions (L x W x H) | Length, handle in operating position: 54.3 inches (1379.2 mm) Width: 27.4 inches (696.0 mm) Height: 42.0 inches (1066.8 mm) Length, operator handle folded: 50.5 inches (1282.7 mm) Height, operator handle folded: 26.2 inches (665.5 mm) |
| Product Weight | 307.0 lbs (139.2 kg), less grinding attachments |
Downloads
| Literature | Description | Version |
|---|---|---|
| SG24GH Legacy Series Dual Head Surface Grinder | GEF01111024 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| SG24 Surface Grinder Operator Manual (With SG12E PGOM v1.0) | GOM3259601 | 1.2 |
| Parts | Description | Version |
|---|---|---|
| SG24 Series Surface Grinder Parts | PGOM3259601 | 1.2 |
| Service information | Description | Version |
|---|---|---|
| J-6250-2 Elastomeric Mount Installation Instructions (All Products Serial Numbers) | GEF24030502 | 2.0 |
| Application Information | Description | Version |
|---|---|---|
| Guide To Silica Dust Control | 1.0 | |
| Silica Dust Written Exposure Plan Template | 1.0 | |
| Get the Facts OSHA Silica Dust Standard | 1.0 | |
| Dispelling the Myths How to Choose a Dust Collection System | 1.0 | |
| Surface Grinder Attachment Application Guide | GEF20090602 | 1.0 |
| MSDS | Version |
|---|---|
| Fuel Stabilizer | 1.0 |
| 300-Series-Transmission-Lubricant | 1.0 |
