Product Description
Features/Benefits:
- Power-GRIP® operator handle for better stance, control plus low vibrations
- Auger-LOK® System, back out stuck augers damage free
- Honda® GX35 all-position engine, no mixing of oil & gas required
- All metal centrifugal clutch for long wear & low maintenance
- Precision, spur gear transmission for problem-free operation
- 1 inch diameter auger drive connection to maximize auger inventory usage
- Magura® twist grip throttle control for safe, non-slip operation
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Digging Applications | Smaller fencing, decks, landscaping & other similar projects in loam, sand, soft clay and granular rubble soil classifications |
| Power Source | |
|---|---|
| Power Source | 1.3 HP (.97 Kw) Honda GX35, all-position, 4 Stroke, gas engine |
| Starter | Hand rewind |
| Fuel | Gasoline, unleaded, automotive grade |
| Transmission & Auger | |
|---|---|
| Transmission | Totally enclosed, cast aluminum housing, precision spur gear, grease lubricated |
| Maximum Digging Torque | 51.0 ft lbs (69.1 N.m.) |
| Nominal Auger Rotation Speed | 166.0 RPM, no load |
| Auger Drive Connection | 1.0 inch (25.4 mm) round |
| Available Auger Diameter Range | Optional 2.25 to 8.0 inches (57.2 to 203.2 mm) |
| Standard Auger Digging Length | 30.0 inches (762.0 mm) |
| Available Auger Extension | Optional 15.0 inch (381.0 mm), plain-tube type |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 25.8 x 13.4 x 15.0 inches (655.3 x 340.4 x 381.0 mm) |
| Product Weight | 26.0 lbs (11.8 kg), less auger |
| Agency Certifications | CE |
INSTRUCTIONAL VIDEOS
How To Chose The Right Hand-Held Hole Digger For The Job
How To Operate A 242H EPIC® Series Hole Digger
How To Operate the Auger-LOK® on a 242H EPIC® Series Hole Digger
Downloads
| Literature | Description | Version |
|---|---|---|
| 242H EPIC® Series One Man Hole Digger | GEF10121901 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| 242H EPIC® Series One Man Hole Digger Operator Manual (EU Version) | GOM08042001EU | 1.1 |
| 242H EPIC® Series One Man Hole Digger Operator Manual (US Version) | GOM08042001US | 1.3 |
| Parts | Description | Version |
|---|---|---|
| 242H EPIC® Series One Man Hole Digger Parts (US Version) | PGOM08042001US | 1.3 |
| Service information | Description | Version |
|---|---|---|
| 242H EPIC® Series One Man Hole Digger Service Manual (EU Version) | PGSM08042001EU | 1.0 |
| MSDS | Description | Version |
|---|---|---|
| 200 Series Transmission Lubricant | 1.0 | |
| LA-170 UV Black Matte | (PV0017 S) 8-28-09 | 1.0 |
| 240 Engine Oil MSDS | 1.0 |
