Product Description
Features/Benefits:
- Auger-LOK® System for convenient, damage-free, stuck auger removal
- .8752 inch square auger drive connection to compliment your Ground Hog type auger inventory
- Power-FLEX® operator handles improve digging stance, dampens kickback, vibrations plus, reduces stress/strain
- All metal centrifugal clutch heat treated for long life and low maintenance
- Precision, spur gear transmission, no slip, no bind, no belts to break
- Honda® GXV160 engine for reliable power & performance
- Magura® twist grip throttle control for safe, non-slip operation
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Digging Applications | Larger fencing, decks, landscaping, sign installations, soil sampling & other similar projects in loam, sand, soft clay plus, sandstone, fractured limestones, caliche, compacted clays & rubble soil classifications |
| Power Source | |
|---|---|
| Power Source | 5.5 HP (4.1 Kw) Honda GXV160, 4-stroke, gas engine |
| Starter | Hand rewind |
| Fuel | Gasoline, unleaded, automotive grade |
| Transmission & Auger | |
|---|---|
| Transmission | Totally enclosed, cast aluminum housing, precision spur gear, oil lubricated |
| Maximum Digging Torque | 190.0 ft lbs (257.6 N.m) |
| Nominal Auger Rotation Speed | 144.0 RPM, no load |
| Auger Drive Connection | .875 inch (22.2 mm) square |
| Available Auger Diameter Range | Optional 4.0 to 18.0 inches (101.6 to 457.2 mm) (Ground Hog®) |
| Standard Auger Digging Length | 36.0 inches (914.4 mm) |
| Available Auger Extension | Optional 15.0 inch (381.0 mm), plain-tube type |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 58.5 x 27.0 x 22.3 inches (1485.9 x 685.8 x 566.4 mm) |
| Product Weight | 77.0 lbs (34.9 kg), less auger |
| Agency Certifications | CE |
INSTRUCTIONAL VIDEOS
How To Chose The Right Hand-Held Hole Digger For The Job
How To Operate A 332H & 348H EPIC® Series Hole Digger
How To Operate the Auger-LOK® on a 262H, 332H & 348H EPIC® Series Hole Digger
Downloads
| Literature | Description | Version |
|---|---|---|
| 348H EPIC® Series Two Man Hole Digger | GEF10121904 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| 332H-348H EPIC® SERIES TWO MAN HOLE DIGGER OPERATOR MANUAL (EU VERSION) | GOM08042003EU | 1.1 |
| 332H-348H EPIC® SERIES TWO MAN HOLE DIGGER OPERATOR MANUAL (US VERSION) | GOM08042003US | 1.3 |
| Parts | Description | Version |
|---|---|---|
| 332H-348H EPIC® SERIES TWO MAN HOLE DIGGER PARTS (US VERSION) | PGOM08042003US | 1.3 |
| Service information | Description | Version |
|---|---|---|
| 332H-348H EPIC® SERIES TWO MAN HOLE DIGGER SERVICE MANUAL (EU VERSION) | PGSM08042003EU | 1.2 |
| MSDS | Version |
|---|---|
| 300 Series Transmission Lubricant | 1.0 |
