Product Description
Features/Benefits:
- Patented clamp system keeps unit secure in forward & reverse cutting directions for zero worries
- No special tools required for installation, decreases install time or need for expensive tools
- Heavy-duty steel frame won’t crack or distort under heavy load for safe operation
- Self-sharpening blade keeps your operations running round the clock, requires no downtime
- High capacity, low-maintenance, sleeve-type bearings for a low-cost, long service life
- Water-free operation, no dust suppression or blade cooling required, reduces operational costs & equipment
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Cutting Applications | Patching, scoring, edging on pipeline, street/road, water/sewer & parking lot construction/repair projects involving asphalt materials for bucket mount setups using lighter equipment including most backhoes, tractor/wheel loaders & similar primary mover vehicles; not for use with skid loaders |
| Maximum Application Bucket Tooth Thickness | 2.5 inches (63.5 mm) |
| Maximum Application Bucket Tooth Width | 6.0 inches (152.4 mm) |
| Frame | |
|---|---|
| Frame | Unitized, welded steel plate |
| Cutting Blade Diameter | 13.5 inches (342.9 mm) |
| Hub/Blade Assembly | Alloy steel blade & welded, machined hub |
| Bearings | Sleeve type |
| Mounting | Twin-pivoting, counter-rotating, clamping screws |
| Maximum Downforce | 25,000.0 lbs (11,339.8 kg) |
| Maximum Cutting Depth | 5.0 inches (127.0 mm) |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 16.9 x 10.5 x 26.5 inches (429.3 x 266.7 x 673.1 mm) |
| Product Weight | 152.0 lbs (68.9 kg) |
DOWNLOADS
| Literature | Description | Version |
|---|---|---|
| 130C CUT-R-TACH® C Series Clamp Mount Attachment | GEF01111012 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| 130 and 190 Series CUT-R-TACH® Operator Manual | GOM-529810-388 | 1.1 |
| Parts | Description | Version |
|---|---|---|
| 130 and 190 Series CUT-R-TACH® Parts | PGOM529810-388 | 1.1 |
