Product Description
Features/Benefits:
- Water-free operation, no dust suppression or blade cooling required, reduces operational costs & equipment
- Self-sharpening blade keeps your operations running round the clock, requires no downtime
- No special tools required for installation, decreases install time or need for expensive tools
- Heavy-duty steel frame won’t crack or distort under heavy load for safe operation
- High capacity, Timken-type bearings providing low maintenance, long service life
Specifications
| Operating Environment | |
|---|---|
| Operating Environment | Non-hazardous type locations |
| Cutting Applications | Larger patching, scoring, edging on pipeline, street/road, water/sewer & parking lot construction/repair projects involving asphalt materials for motor grader with moldboard setups 13 to 28 inches high and 13 inches of lift & similar sized dozer blades, tilting of moldboard permits angle cutting |
| Frame | |
|---|---|
| Frame | Unitized, welded steel plate |
| Cutting Blade Diameter | 19.0 inches (482.6 mm) |
| Hub/Blade Assembly | Alloy steel blade & high-tensile, ductile iron hub |
| Bearings | Timken type |
| Mounting | Fixed & screw adjustable jaws clamped to moldboard |
| Maximum Downforce | 50,000.0 lbs (22,679.6 kg) |
| Maximum Cutting Depth | 5.5 inches (139.7 mm) |
| General | |
|---|---|
| Product Dimensions (L x W x H) | 25.3 x 13.3 x 54.3 inches (642.6 x 337.8 x 1379.2 mm) |
| Product Weight | 323.0 lbs (146.5 kg) |
Downloads
| Literature | Description | Version |
|---|---|---|
| 190M CUT-R-TACH® M Series Moldboard Mount Attachment | GEF01111014 | 1.2 |
| Manuals | Description | Version |
|---|---|---|
| 130 and 190 Series CUT-R-TACH® Operator Manual | GOM-529810-388 | 1.1 |
| Parts | Description | Version |
|---|---|---|
| 130 and 190 Series CUT-R-TACH® Parts | PGOM529810-388 | 1.1 |
