Key Features
How The Campbell Hausfeld GR3200 Compares To The CASTAIR 3-in-1
Contractors evaluating combination compressor/generator/welder units usually face this question: should I get this Campbell Hausfeld GR3200 at a more accessible price point, or the CASTAIR 3-in-1 already in the catalog?
| Feature | Campbell Hausfeld GR3200, 30 Gal, Honda GX390 | CASTAIR 3-in-1, 30 Gal, Honda GX390 |
|---|---|---|
| Compressor Output | 14 CFM at 90 PSI, 175 PSI max | Varies by configuration |
| Pump Design | Two stage, oil-lubed cast iron for quiet operation | Two stage cast iron pump |
| Generator Output | 5,000W continuous, GFCI 120V/240V outlets | Comparable generator output |
| Price | $6,999 | $12,021 |
Product Description
How The Campbell Hausfeld GR3200 Compares To The CASTAIR 3-in-1
Contractors evaluating combination compressor/generator/welder units usually face this question: should I get this Campbell Hausfeld GR3200 at a more accessible price point, or the CASTAIR 3-in-1 already in the catalog?
Here's the honest comparison:
| Feature | Campbell Hausfeld GR3200, 30 Gal., Honda GX390 ($6,999) | CASTAIR 3-in-1, 30 Gal., Honda GX390 ($12,021) |
|---|---|---|
| Engine | Honda GX390, recoil or electric start | Honda GX390 |
| Tank Capacity | 30 gallons | 30 gallons |
| Compressor Output | 14 CFM at 90 PSI, 175 PSI max | Varies by configuration |
| Pump Design | Two stage, oil-lubed cast iron pump for quiet operation and long life | Two stage cast iron pump |
| Generator Output | 5,000 watt continuous, GFCI-protected 120V and 240V outlets | Comparable generator output |
| Welder | DC arc welder, 50A to 200A, welds up to 1/2-in. thick steel | Comparable welder output |
| Certification | ASME certified, UL-certified and OSHA-compliant control panel | Similar industrial certification standards |
| Belt Guard | Heavy-duty 14-gauge steel belt guard, securely bolted, easily removable for maintenance | Comparable guard construction |
| Best Suited For | Contractors wanting proven 3-in-1 functionality at a more accessible price point | Contractors prioritizing CASTAIR's specific configuration and brand |
Why The Campbell Hausfeld GR3200 Is Worth The Investment
This isn't just a compressor, it's a genuine 3-in-1 machine combining a two-stage compressor, a 5,000 watt generator, and a 200A DC arc welder in a single ASME certified unit, giving contractors the equivalent of three separate pieces of equipment without the cost, space, or maintenance burden of owning them individually.
The GR3200 specifically addresses the needs of contractors, service trucks, and jobsite crews who need compressed air, generator power, and welding capability all available from a single machine mounted on the truck or trailer.
Three Machines, One Compact Footprint. Eliminating the need for a separate compressor, generator, and welder, this unit consolidates all three functions into one ASME certified package, freeing up truck bed or trailer space that would otherwise be taken up by three individual machines.
Built For Reliable, Multi-Function Performance
The two stage, oil-lubed cast iron compressor pump delivers 14 CFM at 90 PSI with quiet operation and long service life
The 5,000 watt generator provides GFCI-protected 120V and 240V outlets for powering electric tools and lights
The onboard DC arc welder ranges from 50A to 200A, capable of welding up to 1/2-in. thick steel
Engineered For Jobsite Durability And Safety
The UL-certified, OSHA-compliant control panel keeps operation safe and compliant on active jobsites
A heavy-duty 14-gauge steel belt guard is securely bolted for protection but quickly removable for routine maintenance
The reliable Honda GX390 engine features a 12V alternator with recoil or electric start options
Real Savings
Combining three machines into one unit avoids the cost of purchasing a separate compressor, generator, and welder
ASME certification and a two-stage cast iron pump reduce the risk of premature pump failure under heavy use
Consolidating equipment onto one unit reduces the truck bed or trailer space needed for job site equipment
Free shipping and no sales tax through Summit Forge Supply keeps the total cost down compared to buying elsewhere and paying tax and freight separately
The Bottom Line Contractors and service crews who need compressed air, generator power, and welding capability on the job site can't afford to haul three separate machines when one unit can do it all. The Campbell Hausfeld GR3200 is built with a reliable Honda GX390 engine, a two-stage cast iron compressor pump, a 5,000 watt generator, and a 200A DC welder, so it delivers genuine 3-in-1 jobsite utility. For anyone who needs air, power, and welding capability on the truck or trailer, this is the machine built to handle all three.
- ASME certified combination air compressor, generator, and welder
- Two stage oil-lubed cast iron pump for quiet operation and long life
- 14 CFM at 90 PSI, 13.7 CFM at 175 PSI
- 30 gallon air tank with slots for forklift transport
- 14 gauge steel guard keeps belt totally enclosed during operation
- 5000 watt running, 6000 surge watt output
- Two 120V outlets, and one 240V outlet, all GFCI protected
- 50A to 200A DC arc welder welds up to ½ In. thick steel work pieces
- Welder duty cycle: 150A = 100%, 180A = 65%
- Industrial grade Honda GX390 engine 12-volt alternator, recoil and electric start, and 1.6 gallon fuel tank
- UL certified and OSHA compliant control panel
| Equipment Type | 3-in-1 Gas Powered Air Compressor/Generator/Welder |
| Engine Brand | Honda |
Full Spec Sheet
| Model | GR3200.SAN |
| Equipment Type | 3-in-1 Gas Powered Air Compressor/Generator/Welder |
| Engine | Honda GX390, 12V alternator, recoil/electric start |
| Fuel Tank | 1.6 gal |
| Compressor Output | 14 CFM at 90 PSI, 13.7 CFM at 175 PSI |
| Tank Capacity | 30 gal, forklift transport slots |
| Generator Output | 5,000W running, 6,000W surge |
| Outlets | Two 120V, one 240V, all GFCI protected |
| Welder | DC arc, 50A-200A, up to 1/2 in steel |
| Welder Duty Cycle | 150A at 100%, 180A at 65% |
| Certification | ASME certified, UL-certified/OSHA-compliant control panel |
