Product Description
Additional Specifications:
Wheels: 3
Contact Wheel Size: 4-3/4″ x 1″
Throat Clearance: 5-1/2″
Contact Wheel Hardness: 55 Duro
Belt Tension Quick Change Assembly: Yes
Positive Belt Tracking Adjustment: Yes
Overall Height, Width, Depth: 20″ x 17″ x 15″
Safety Belt Guard: Yes
Base Area: 10″ x 13″
Steel Backup Platen: 1-1/8″ x 5″ x 1/8″
Adjustable Work Rest: Yes
Construction: Cast Aluminum
Bench or Pedestal Mounted: Yes
Process Evaluation: Grinding
Pedestal Included: No
Main Application: Belt Grinding
Additional information
| Weight | 85 lbs |
|---|---|
| Belt Size |
1 x 42 |
| Speed Fixed |
No |
| Speed Variable |
530-5300 SFPM |
| HP |
3/4 |
| Volt/Phase |
120/1 |
| Hz |
50-60 |
| Country of Origin |
USA |
