With its variable speed blower motor and two stage burner, the ACiQ G80CTL0702120A can provide a consistently superior comfort to almost any application.
QUICK FACTS
- 66,000 BTU, 80% AFUE natural gas furnace
- Generally suitable for up to a small to medium house in ideal applications
- Communicating variable speed blower with a two stage burner
- Multi-positional design - can be installed in the upflow, downflow, or horizontal orientations
- California Low NOx compliant
- Field-convertible to propane with an optional LP kit
- On board self-diagnostics
66,000 BTU, 80% AFUE
The ACiQ G80CTL0702120A has an input of 66,000 BTU. With an efficiency of 80%, this means that the furnace has an output of 53,000 BTU. The 80% AFUE also means that for the gas going into the furnace, 80% of it is used to heat your home while the remaining 20% is lost out the flue piping and lost to normal furnace operations. All 80% furnaces require metal flue venting, and if you need it to be plastic/PVC venting a furnace with an efficiency of 90% or above is required. While this unit uses natural gas as fuel out of the box, we also have an LP conversion kit, available at an additional cost.
Warranty
ACiQ offers a 10 year no hassle unit replacement, 10 year parts, and lifetime heat exchanger limited warranty. Please note that in order for the heat exchanger and parts warranties to be upheld, the unit must be registered through the manufacturer within 90 days of installation. The installation must also follow your state and local codes.
Installation and Durability
With its ability to be installed in any configuration (upflow, downflow, or horizontal), the ACiQ G80CTL0702120A is very versatile in application potential. The unit has a durable outer casing that can withstand wear-and-tear through its entire lifetime, providing the peace of mind that your home will stay comfortable year-round. Please note that this furnace is not designed to be suitable for a mobile home on its own.
Superior Comfort
All ACiQ-brand equipment is manufactured, one of the leaders of superior comfort in the industry. The ACiQ G80CTL0702120A definitely lives up to the name thanks in part to its communicating variable speed blower motor and its two stage burner. Both of these prominent features provide the most precise temperature and airflow output possible, making you as comfortable as possible in your home year-round.
| ACiQ 80% 60,000 BTU Two Stage Gas Furnace - 21" Width - Multi-Positional |
| Feature |
Spec |
| SKU |
G80CTL0702120 |
| Weight |
146.000000 |
| AHRI Certificate Number |
213148662 |
| Exhaust Flue Requirement |
Metal |
| Manufacturer |
ACiQ |
| Equivalent |
Carrier Equivalent: 58TN0A070C21--20
Tempstar Equivalent: F80CTL0702120A
Bryant Equivalent: 880TA60070C21
|
| Product Features |
Low NOx, New Refrigerant Compliant |
| Furnace Efficiency / AFUE |
80% |
| Heating BTU |
66,000 |
| Blower Motor |
Variable Speed - ECM |
| Maximum CFM |
2150 |
| Configuration |
Upflow/Downflow/Horizontal |
| Electrical |
115v 1 Phase 60 Hz |
| Burner Stages |
Two |
| Ignition Type |
Direct Ignition with Silicon Nitride Hot Surface Ignitor |
| Fuel Type |
Propane, Natural Gas |
| Height |
33 1/3" |
| Width |
21" |
| Depth |
29" |
| Warranty |
10 Year No Hassle Replacement / Lifetime Heat Exchanger and 10 Year Parts with Online Registration |
| Resources |
You will need Adobe® Acrobat® Reader to view PDF documents. |
| Safety Information |
This gas appliance requires a trained technician to install. Improperly connecting gas lines or improperly connecting a gas flue or venting may result in death. By purchasing this item, you are agreeing that you are using a trained technician to install this gas appliance. We will not be responsible for any injury or property damage arising from improper service or service procedures. Whoever installs or services this unit assumes responsibility for any personal injury or property damage which may result. Many jurisdictions require a license to install this equipment.
