Key Features
✓
Compact design fits job sites with limited space where larger pumps of similar capability can't
✓
Delivers up to 20 cubic yards per hour of concrete, shotcrete, and high-strength grouts
✓
3-cylinder liquid-cooled 28 HP diesel engine
✓
2-cylinder pumping system with hydraulic control
✓
Automatic greasing system reduces maintenance downtime
✓
Includes heavy-duty highway tow package
Product Description
Although it has high-performance output, the compact design of the Booster 20 allows it to function on job sites with limited space - where no other pumps of its capability could fit. This pump is designed and built to provide up to 20 cubic yards per hour of concrete, shotcrete, and high strength grouts.
| Model # | 1106427 |
| Engine | 3 Cylinder Diesel |
| Engine Power | 28 HP |
| Pumping System | 2- Cylinder w/ Hydraulic Control |
| Max Aggregate | 1 in |
| Flow Rate | 3 - 20 cu yd / hr |
| Pumping Pressure | 1,000 psi |
| Outlet | 4 in HD |
| Hopper Capacity | 7 cu ft |
| Loading Height | 42.5 in |
| Dimensions w/l/h | 58 in x 161 in x 60 in |
| Weight | 3,100 lbs |
Standard Equipment
- 3-cylinder liquid cooled, 28 HP, diesel engine
- Automatic greasing system
- Concrete hopper with agitator
- Vibrating grid, 12V
- Hydraulic system with reverse
- Pumping unit with S-valve with automatic compensation of clearance and wear
- 4" Heavy Duty delivery manifold
- Control panel with electromechanical controls
- Piston head installation and extraction tool kit
- Complete w/ heavy duty highway tow package
- Accessory box with grease pump
- Centralized grease ports
- 4" Cleaning balls
Downloads
Full Spec Sheet
| Model | 1106427 |
| Engine | 3-cylinder diesel, 28 HP |
| Pumping System | 2-cylinder, hydraulic control |
| Max Aggregate | 1 in |
| Flow Rate | 3-20 cu yd per hr |
| Pumping Pressure | 1,000 psi |
| Weight | 3,100 lbs |
